ace5000™
Interseal Sealing Technology
Technologies
The Smart Business Choice
Interseal, a leader in sealing technology products, has developed an innovative sealing system called ace5000™ for the Indian market.
The Interseal ace5000™ works on the principle of multiple lip-sealing technology and eliminates the requirement of not only a barrier-fluid but also any chances of seal-face contamination into the product. The specially developed system between the shaft protection sleeve and the sealing lips ensures that no liquid or gas must be used. Therefore, the ace5000™ sealing system does not require any fluid supply systems.
The ace5000™ runs dry and ensures that your process runs permanently smooth
As the ace5000™ does not require lubrication, it reduces the risk of production loss to an absolute minimum and protects people and the environment.
Applications: The ace5000™ sealing technology can be used in all types of applications such as API, cGMP areas, sterile operations, crystallization, high vacuum, finish product area, high viscous process, and frequent seal failures.
| Shaft Diameter (mm) | Operating Pressure | Temperature | Maximum sliding velocity |
|---|---|---|---|
| 40- 160mm | Full vacuum to 6 bar |
-40°C to +220°C | 3m/s |
Key design features:
- Dead space minimized design
- Intelligent sealing technology
- cGMP design offered as standard
- CIP: Easy cleaning
- FDA certification
- ATEX certification
- No-start up requirements
Advantages:
- Reduced Total Cost of Ownership
- Predictive sealing failure mechanism
- No risk of overheating with temperature monitoring
- Easy and clear spare parts concept
- Dedicated after-sales and services team
